Plastic Processed:
PP, PC, PET
Condition:
New
Style:
Horizontal
Distance between Tie Bars(Width)(mm):
355mm
Distance between Tie Bars(Height)(mm):
315mm
Mold Height(mm):
150 - 380 mm
Ejector Stroke(mm):
70 mm
Ejector Force(kN):
27 kN
Theoretical Shot Volume(cm³):
190 cm³
Injection Rate (g/s):
78 g/s
Machine Type:
Hydraulic
Injection Weight (g):
173 g
Screw Speed (rpm):
1 - 200 rpm
Screw diameter (mm):
38 mm
Distance between Tie Bars:
355mm*315mm
Weight (KG):
2700
Type:
Tube Head Injection
Place of Origin:
Zhejiang, China
Open Stroke(mm):
280 mm
Model Number:
FHG-100
브랜드 이름:
FUHONG
Power (kW):
9 kW
Warranty:
2 years
Key Selling Points:
Energy saving
Applicable Industries:
Manufacturing Plant
Showroom Location:
None
Marketing Type:
New Product 2020
Machinery Test Report:
Provided
Video outgoing-inspection:
Provided
Warranty of core components:
1 Year
Core Components:
Motor, Pump, Other, Pressure vessel
After-sales Service Provided:
Engineers available to service machinery overseas, Video technical support, Free spare parts, Field installation, commissioning and training, Field maintenance and repair service, Online support
Plastic Type:
Thermoplastic
Automatic:
Yes
Space between Tie Bar:
355mm*315mm
Mould thickness:
150mm-380mm
Ejector stroke:
70mm
Ejector force:
27kn
System pressure:
16Mpa
Pump motor:
9kw
Heating capacity:
6.9kw
After Warranty Service:
Online support
Local Service Location:
None
인증:
CE TUV
