PIPE CE / ISO Certification 4 Co-extruder Single Extruder Screw

1.0 Sets
MOQ
PIPE CE / ISO Certification 4 Co-extruder Single Extruder Screw
풍모 갤러리 제품 설명 따옴표를 요구하십시오
풍모
제품 사양
Application: PIPE, Sheet, Profile
Plastic Processed: PE/PP
Condition: New
Screw Design: Single-screw
Screw Material: 38CrMoALA
Screw diameter (mm): 75 mm
Screw Speed (rpm): 100 rpm
Showroom Location: None
Place of Origin: Jiangsu, China
브랜드 이름: Huaming
Voltage: 380V 50HZ 3Phase(Customized)
Dimension(L*W*H): 29-48*1.5-3.0m
Power (kW): 90
Weight: 5-15T
Warranty: 1 Year
Key Selling Points: Sustainable
Applicable Industries: Manufacturing Plant
Marketing Type: Ordinary Product
Video outgoing-inspection: Provided
Machinery Test Report: Not Available
Warranty of core components: 1 Year
Core Components: Motor
After-sales Service Provided: Engineers available to service machinery overseas, Field installation, commissioning and training
color: as clients' requirement
Automatic Grade: Automatic
After Warranty Service: Video technical support
Local Service Location: None
인증: CE ISO
기본 정보
Place of Origin: Jiangsu, China
브랜드 이름: Huaming
인증: CE ISO
결제 및 배송 조건
Packaging Details: Standard export packing- wooden cases
Supply Ability: 30 Set/Sets per Month
제품 설명

Single-screw Screw Design and New Condition





1.Usage and scope of application

PE PP PPR pipe extrusion equipment  is mainly used in the production of water supply and drainage pipes , which used for agriculture and construction , cable coating and other fields.

The production line is mainly used to produce large diameter pipes for water supply, drainage, gas supply, chemical, agricultural irrigation, and daily life, etc.



2.Configuration

PE PP PPR pipe extrusion equipment  is consisted of extruder , vacuum calibrator , hauling machine ,cutter and tipping rack , hauling machine unit has come ways of hauling , such as crawler-type, three-claw type , four-claw type , six-claw type and so on . There are also knife-lifting cutter and planetary cutter.



3.Machine composition & characteristics

The advantages of this HDPE pipe production line are as follows: unique structure, advanced automation, easy operation, and stable continuous production. The pipe produced by this HDPE pipe production line is the first choice for gas supply and outdoor water supply because of properly rigidity and strength, also possess good flexibility, creep resistance, environmental stress cracking resistance and good thermal fusion welding performance.

The production line consists of control system, screw extruder, die, setting& cooling system, haul-off machine, cutter and reversing device. Normally the production line has two extruders, one is high efficient HDPE specialized screw extruder, the other smaller one is used to extrude marker line.

Mould and auxiliary machines: the die we use is basket type or spiral shunt type complex extrusion die. The advantages of such kind of die are easy adjust and even discharging. The diameter control unit is processed through unique grooving and water ring cooling to guarantee the pipe molding precision. Regarding to the auxiliary, use high efficient double chamber vacuum sizing technology and spray cooling water tank to improve the pipe yield and meet high speed production requirement. About the large diameter pipe, use tractor which is controlled by ac variable-frequency motor. The motor is driven by energy-efficient inverter to ensure the precise speed regulation and it synchronous with extruding process. Use high speed and precisely designed cutter to make the cutting surface evenly. The cutter is fixed with powerful suction device to collect the waste so as to save maintenance.





Product Description



Pipe range

16-63mm

20-110mm

75-160mm

90-250mm

110-315mm

160-450mm

315-630mm

500-800mm

Extruder

¢45mm

¢60mm

¢75mm

¢75mm

¢90mm

¢90mm

¢120mm

¢150mm

Extruder power

AC30kw

DC75kw

DC110kw

DC110kw

DC160kw

DC160kw

DC280kw

DC335kw

Extrusion capacity

60-100kg

100-150kg

250-300kg

250-300kg

350-400kg

350-400kg

650-700kg

850-900kg

Max. production speed

10m/min

6m/min

6m/min

6m/min

3 m/min

1.2m/min

0.9m/min

0.7m/min
